Name: Street Centerlines

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This file contains the centerline of all named and unnamed roads, alleys, gravel, dirt, bike, walking trails and other relevant features in Okaloosa County. If a segment is part of a named, street it will have address ranges attached to each side of the segment and list the official 911 street names. If a segment is not part of a named street it will not have address ranges and not be named, however, it will have the TRANS-TYPE (transportation type or surface type) coded. These arcs are left in the file and are used for display purposes only. Okaloosa County GIS Division divided the County into 4 Phases. Purpose for rdsmn.aat To enable all addresses within Okaloosa County to be located using address geocoding. This shapefile allows the program to estimate the location of an address based on the length of the segment and the address range assigned to the segment. For example, an address of 49 Main Street would plot in the middle of a Main Street segment with an address range of 1-99 on one side and 2-100 on the other.

Service Item Id: 518f6efd7a624ac9864f8893c902994b

Copyright Text: Okaloosa County GIS Department

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 75000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -9664052.710475529
YMin: 3551597.790765276
XMax: -9614181.496266881
YMax: 3633178.6465134625
Spatial Reference: 102100  (3857)  VCSWkid(115700)  LatestVCSWkid(115700)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: OWNER
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Forest
  Label: Forest; Military
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: Military
  Label: Forest; Military
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: Gated
  Label: Gated
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 2
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 12
Font Family: Arial Black
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 7000.0
Max. Scale: 0.0
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 12
Font Family: Arial Black
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• TRANS_TYPE ( type: esriFieldTypeSmallInteger, alias: TRANS_TYPE )
• OWNER ( type: esriFieldTypeString, alias: OWNER, length: 12 )
• MSAGNAME ( type: esriFieldTypeString, alias: MSAGNAME, length: 56 )
• PREDIR ( type: esriFieldTypeString, alias: PREDIR, length: 2 )
• PRETYPE ( type: esriFieldTypeString, alias: PRETYPE, length: 4 )
• NAME ( type: esriFieldTypeString, alias: NAME, length: 42 )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 4 )
• SUFDIR ( type: esriFieldTypeString, alias: SUFDIR, length: 2 )
• L_ZIP ( type: esriFieldTypeString, alias: L_ZIP, length: 5 )
• R_ZIP ( type: esriFieldTypeString, alias: R_ZIP, length: 5 )
• L_ZIP_CITY ( type: esriFieldTypeString, alias: L_ZIP_CITY, length: 50 )
• R_ZIP_CITY ( type: esriFieldTypeString, alias: R_ZIP_CITY, length: 50 )
• VICINITY ( type: esriFieldTypeString, alias: VICINITY, length: 50 )
• LF_ADD ( type: esriFieldTypeInteger, alias: LF_ADD )
• LT_ADD ( type: esriFieldTypeInteger, alias: LT_ADD )
• RF_ADD ( type: esriFieldTypeInteger, alias: RF_ADD )
• RT_ADD ( type: esriFieldTypeInteger, alias: RT_ADD )
• L_PAR ( type: esriFieldTypeString, alias: L_PAR, length: 1 )
• R_PAR ( type: esriFieldTypeString, alias: R_PAR, length: 1 )
• SHIELD_NUM ( type: esriFieldTypeString, alias: SHIELD_NUM, length: 6 )
• TF_MPH ( type: esriFieldTypeSmallInteger, alias: TF_MPH )
• FT_MPH ( type: esriFieldTypeSmallInteger, alias: FT_MPH )
• L_ESN ( type: esriFieldTypeSmallInteger, alias: L_ESN )
• R_ESN ( type: esriFieldTypeSmallInteger, alias: R_ESN )
• L_ESN_DESC ( type: esriFieldTypeString, alias: L_ESN_DESC, length: 50 )
• R_ESN_DESC ( type: esriFieldTypeString, alias: R_ESN_DESC, length: 50 )
• LF_CRST ( type: esriFieldTypeString, alias: LF_CRST, length: 42 )
• RF_CRST ( type: esriFieldTypeString, alias: RF_CRST, length: 42 )
• LT_CRST ( type: esriFieldTypeString, alias: LT_CRST, length: 42 )
• RT_CRST ( type: esriFieldTypeString, alias: RT_CRST, length: 42 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape.len )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
